| Form Factor: | Mini-ITX, MicroATX, ATX, E-ATX up to 272mm(10.71inch) |
| Cooling: | Fan Support(Front):3 x 120mm or 3 x 140mm; Fan Support(Top):3 x 120mm or 3 x 140mm; Fan Support(Rear):1 x 120mm or 1 x 140mm; Included Fans(Front):3 x 140mm Fan; Included Fans(Rear):1 x 120mm Fan (+5V 3Pin ARGB) x1; Radiator Support(Front):240mm /280mm/360mm; Radiator Support(Top):240mm /280mm/360mm; Radiator Support(Rear):120mm/140mm |
| I/O: | 2 x USB 3.0, Audio IO ,USB Type-C x1 |
| Slots for devices: | 2.5" Drive Bay:4+2 (1 for controller installation); 3.5" Drive Bay:4 |
| Expansion Slots: | 7 horizontal + 3 vertical |
| Materials: | Steel, Plastic, Tempered Glass |
| Weight: | 8.30 kg |
| Dimensions: | 225x494x475(mm) |
| Other: | Maximum CPU Cooler Height:180(mm)/ 7.09(inch); Maximum Graphics Card Support:410mm(16.14inch) (Suggest to 400mm); Cable Management Space:22mm(0.87inch) from motherboard tray to side panel/40mm(1.57inch) from cable manage cover to side panel;ATX & Standard / up to 200mm(7.87inch) |
| Сайт на производителя: | https://www.bitfenix.com/products/chassis-2/eatx/tracery/specs/ |
