| Form Factor: | Mini-ITX, MicroATX, ATX, E-ATX up to 275mm(10.8inch) |
| Cooling: | Fan mounts(Front):3 x 120mm or 2 x 140mm; Fan mounts(Top):2 x 120mm or 2 x 140mm; Fan mounts(Rear):1 x 120mm; Fan mounts(Bottom):1 x 120mm; Pre-installed Fans(Front):120mm Black Fan x2; Pre-installed Fans(Rear):120mm Fan (+5V 3Pin ARGB) x1; Radiator Support(Front):240mm x 1/ 280mm x 1/ 360mm x 1(Thickness up to 35mm/ width up to 141mm); Radiator Support(Top):240mm x 1 /280mm x 1; Radiator Support(Rear):120mm x 1 |
| I/O: | 2 x USB 3.0, Audio IO ,USB 3.1 Gen 2 Type-C x1 |
| Slots for devices: | 5.25" Drive Bay:0; 3.5" Drive Bay:2+2; 2.5" Drive Bay:4+1 |
| Expansion Slots: | 7 |
| Materials: | Steel, Plastic, 3 side tempered glass with automotive window security films |
| Weight: | 9.87 kg |
| Dimensions: | 220mm(8.7inch) x 485.5mm(19.1inch) x 449mm(17.7inch) |
| Other: | E-ATX Motherboard Supports:305mm(12 inch) x 275mm(10.8inch); Air Cooler Height Support:165mm(6.5inch); VGA Length Support:380mm(15inch); Power Supply:ATX & Standard / up to 220mm(8.7inch) |
| Сайт на производителя: | https://www.bitfenix.com/products/chassis/eatx/dawn-tg/dawn-tg-specs/ |
