J3355B-ITX_3Y
ASROCK Main Board Desktop (J3355 2.5GHz, DDR3 SO DIMM, 1xPCI 2.0x1,HDMI,VGA, 8ch, GLan,SATAIII,COM, LPT) Mini-ITX Box
| Марка | ASROCK |
|---|---|
| Гаранция | 2 години гаранция |
| Сертификати | FCC, CE, WHQL, ErP/EuP ready |
|---|---|
| Warranty Term (month) | 24 month(s) |
| Warranty Products Returnable | Да |
| Warranty Validation Criteria | Serial Number |
| Height (mm) | 170 mm |
| Width (mm) | 170 mm |
| CPU Socket Standard | Socket 1296 |
|---|---|
| CPU Core Quantity | 2 |
| CPU Installed Quantity | 1 |
| CPU Installed Name | Intel Celeron Processor J3355 |
| Тип памет | DDR3 SDRAM |
|---|---|
| Честота на паметта | 1333MHz(PC3-10600) , 1600MHz(PC3-12800) , 1866MHz(PC3-14900) |
| Форм фактор на паметта | SODIMM 204-pin |
| Memory Features | Two DDR Channels , Unbuffered |
| Maximum Installable System Memory Storage Capacity | 16 GB |
| Memory Slot Total Quantity | 2 |
| Installed L2 Cache Memory Storage Capacity | 2 KB |
| Video Memory Type | Shared Video Memory |
| Storage Controller Form Factor | integrated |
|---|---|
| Storage Controller Type | SATA III |
| Audio Interface | 1 (3.5-mm minijack x 3) |
|---|---|
| Audio Output Mode | 7.1 Channel Surround |
| Audio Chipset | Realtek ALC887 |
| Audio Integrated | да |
| Compliant Audio Standards | High Definition Audio , ELNA Premium Audio Capacitors |
| USB портове | 1 (4-pin USB (type A)) |
|---|---|
| USB портове | 3 (USB 3.0 (Type A)) |
| HDMI | 1 |
| Cable Included | 2 x SATA 6Gb/s Cables |
| Power Connectors Type | 24 pin |
| PCI Express 2.0 x16 Slot Quantity | 1 |
| LAN | 1 (RJ-45) |
|---|---|
| LAN Chipset | Realtek RTL8111GR |
| LAN Integrated | да |
| Data Link Protocol Supports | Gigabit Ethernet/Fast Ethernet/Ethernet |
| Форм фактор | Mini-ITX |
|---|---|
| Box Weight Brutto (kg) | 16 kg |
| BIOS Features | PnP Support , SMBIOS 3.0 Support , 64Mb AMI UEFI Legal BIOS with GUI support , PXE boot , ACPI 5.0 Support , Jumperfree Support |
|---|---|
| BIOS Type | AMI |
| Тегло на опаковката | 0.6 kg |
|---|---|
| Брой на палет | 1 |
| Pack Weight Brutto (kg) | 0.8 kg |
| Packs in Box | 20 |
| Pack Weight Netto (kg) | 0.6 kg |
| Package Type | Retail |
| VGA | 1 (15-pin D-sub) |
|---|---|
| PS/2 | 2 |
| Device Location | Integrated |
| Included Accessories | I/O Shield , CD, Software , Quick Start Guide |
| Parallel | 1 |
| Provides Error Checking Method | non-ECC |
| SATA III | 2 |
| Hardware Monitoring | Chassis Fan Tachometer , CPU Fan Tachometer , CPU Temperature , CPU Quiet Fan , Chassis Temperature Sensing , Chassis Quiet Fan , CPU Fan multi-speed control , Chassis Fan multi-speed control |
| Internal Clock Rate | 2.5 GHz |
| Serial | 1 |
| Video Chipset | Intel HD Graphics 500 |
| Video Controller Integrated | да |
| Wake up/Sleep | Wake on LAN , Wake on WAN |
